Commercial Tankless Electric N Series

Applications for parts washing, heating corrosive liquids and potentially explosive environments. Markets include mining, breweries/wineries, petrochemical, food & beverage, agriculture/livestock, lumber/pulp/papermills, waste water treatment plants, power generation and nuclear.

Find a Distributor

The Laars Heating Systems N Series (Formerly CNA) tankelss electric water heaters are designed specifically for heavy industrial fluid applications. Heaters activate only when needed and provide an unlimited supply of hot water to meet the needs of your heavy industrial application. Heaters activate at 1.5 gpm (5.7 lpm) and can handle water flow up to 50 gpm (189 lpm).

The N Series is suited to a variety of large industrial markets including mining, breweries and wineries, power generation, petrochemical, agricultural and water treatment plants.

kW Range: 36 - 144 kW

Flow Range: 1.5 - 50 gpm (5.7 - 189 lpm)

Standard Voltages: 480V, 600V 3-Phase

2D/3D CAD Files Find a Distributor

{offerCount} rebate{s} up to {totalAmount}

{offerCount} rebate{s} available

Standard Features

PID Temperature Controller
Simple Touch Operation
Precise Temperature Range & Flow
Incoloy 800 Elements
Low Watt Density Element
Recirculation Capable
Liquid-Cooled Solid State Relays
Auto Reset High Limit Switch
Bi-metal Manual Resets
NEMA 4 Enclosures
Independant & Redundant Safeties
Durable Plumbing Assembly
Reliable Performance & Minimal Maintenance

Optional Features

NEMA 4X Enclosures
Building Management Systems Integration
High Temperature Package
Internal Fused Disconnect
Integral Ground Fault
ASME Heat Exchanger
Freeze Protection Package
Explosion-Proof Purge System
