High-Efficiency
Laars Plate™
The Laars Plate™ packaged system is ready to handle specs with unique water heating needs not met through traditional volume water heaters.
Find a Distributor
Semi-instantaneous Double Wall Plate Water Heater
HIGH EFFICIENCY
High heat transfer, water-to-water plate and frame heat exchanger specifically to satisfy commercial potable water heating needs.
UNMATCHED TEMPERATURE CONTROL
Advanced PID control, with feed forward real-time load tracking, quickly responds to variable load patterns to maintain accurate hot water temperatures.
HIGH DOMESTIC WATER OUTPUT
Efficiently produces up to 150 GPM of domestic hot water when coupled with a boiler.
FLEXIBILITY
Controls are user configurable, two-way operation available when used with VFD pumps, and an optional communications gateway is available for additional communication protocols.
SMALL FOOTPRINT
Compact design is ideal for use in commercial and institutional environments where space is not available for large storage tanks.
BUILDING MANAGEMENT SYSTEMS
Controls integration is via Modbus, BACnet or domestic supply water temperature control.Laars Plate™ Details
| Doc No | Rev | Category | Description | View | |||
|---|---|---|---|---|---|---|---|
| Brochures | Brochures | ||||||
| 1437 | B | Brochures, Sales Literature | Laars Plate™ Brochure | Download | |||
| 1437-FR | A | French Documents | Laars Plate | Download | |||
| Drawings | Drawings | ||||||
| 10095 | 2D / 3D CAD Files | 2D/3D CAD Laars Plate™ Drawing | Download | ||||
| Install and Operating Manuals | Install and Operating Manuals | ||||||
| 1432 | Manuals | Laars Plate™ Install and Operating Manual | Download | ||||
| 1432-FR | French Documents | Laars Plate | Download | ||||
| Specification Sheets | Specification Sheets | ||||||
| 11083 | Specification Sheets | Laars Plate™ Specification Sheet | Download | ||||
| Submittal Data | Submittal Data | ||||||
| 11084 | A | Submittal Documents | Laars Plate™ Submittal Data | Download | |||
| 11084-FR | French Documents | Laars Plate | Download | ||||
| Warranty | Warranty | ||||||
| 8066 | Warranty | Laars Plate™, Semi-Instantaneous, Warranty | Download | ||||
